Beverages

Amidst the explosive growth of niche market segments—such as freshly brewed tea beverages, cup-packaged yogurt, and fruit juices—cup filling and sealing machines have emerged as a critical pillar supporting scenario-based production within the beverage industry. Unlike equipment designed for bottles or cans, cup filling and sealing machines must accommodate the unique physical characteristics of disposable cups (whether plastic, paper, or biodegradable materials). They are engineered to balance the "small-batch, multi-specification" demands of retail outlets with the "large-scale mass production" requirements of factory environments.

Through customized technical solutions, precise parameter control, and efficient process design, these machines achieve universal compatibility across the entire product spectrum—from freshly prepared milk tea to cup-packaged fruit juices—thereby becoming essential equipment for beverage companies seeking to expand their consumer scenarios.

I. Scenario Segmentation: A Dual-Adaptation Solution for Retail Stores and Factories

Based on specific application scenarios, our cup filling and sealing machines are organized into two distinct product matrices, precisely tailored to match varying production capacities and operational requirements:

Application Scenarios	Equipment Types	Key Features	Capacity Parameters	Typical Application Cases
Tea shop	Small Inline Filling and Sealing Machine	Footprint ≤ 1.5 m² \| One-touch Operation \| 3–5 Minute Changeover	1500-3500cups/hour	Mixue Ice Cream & Tea / Heytea In-Store Freshly Prepared Milk Tea Production Lines
Chain Brand Central Kitchen	Medium Modular Filling and Sealing Machine	Multi-channel Design \| Intelligent PLC Control \| Supports Storage of 100 Parameter Sets	5000-8000cups/hour	Naixue's Tea Bottled Juice Central Factory Production Lines
Large-scale Food Enterprises	Large Rotary Filling and Sealing Machine	High-speed Continuous Operation \| Integrated Line Synchronization	9000-10000cups/hour	Yili Cup Yogurt Automated Production Lines

II. Core Technologies: Precise Innovation Tailored to Cup Types and Beverage Characteristics

Addressing the unique characteristics of cup-based packaging, our Cup Filling and Sealing Machines have achieved three major technological breakthroughs to resolve key industry pain points:

**1. Multi-Material Cup Compatibility Technology**

**Compatibility Range:** PP cups, paper cups, and biodegradable PLA cups (Cup Diameter: 50–100 mm; Cup Height: 80–200 mm).

**Technical Highlights:** Features a flexible pressure head combined with an adaptive temperature control system. Designed to prevent scorching in paper cups and deformation in PLA cups, the sealing temperature is precisely controlled within an adjustable range of 120–180°C.

**2. Precision Filling and Anti-Drip Design**

**Technical Approach:** Piston-type / Volumetric Cup filling (for fluid beverages); Screw-type filling (for beverages containing particulates, such as bubble tea).

**Key Parameters:** Filling error margin of ±0.8%. The anti-drip filling nozzle utilizes a silicone seal combined with a negative-pressure suction mechanism, ensuring material residue remains ≤0.1g per fill.

**Advantages:** Specifically designed for beverages containing particulates—such as bubble tea and smoothies—this system prevents nozzle clogging and ensures consistent volume in every cup.

**3. High-Efficiency Sealing and Freshness Preservation Technology**

**Sealing Methods:** Heat sealing (using aluminum foil or PE film); Electromagnetic induction sealing (requires metal-based film).

**Core Metrics:** Sealing peel strength ≥15N; Sealing integrity pass rate of 99.92%; Extends the beverage shelf life by 3–7 days at room temperature.

III. Market Size Overview: Dual-Dimensional Growth—Global and China

1. Global Market Size and Growth Rate

Overall Scale: In 2025, the global market for cup filling and sealing machines is estimated at approximately US$2.847 billion (approx. RMB 20 billion). This figure is projected to reach US$4.923 billion by 2035, representing a Compound Annual Growth Rate (CAGR) of 5.6%.

Segmented Models: High-end rotary models exhibit faster growth; their market size is estimated at approximately US$704 million in 2025 and is projected to reach US$1.106 billion by 2032, with a CAGR of 6.7%.

Regional Distribution: The Asia-Pacific region holds the largest market share (42%), followed by North America (23%) and Europe (21%); Latin America and the Middle East & Africa regions demonstrate the fastest growth rates (CAGR of 7.2%).

2. China Market Size and Structure

Overall Scale: In 2025, the market size in China is estimated to range between RMB 5.8 billion and RMB 6.2 billion, with a CAGR of 13.5%—significantly higher than the global average.
